BLR 2 LITE MKIII
#82BLD320
AoIP Blueline receiver. 1 stereo channel. PoE power supply or external source.
BLR2 LITE MKIII is a stereo channel audio over IP receiver. With it you can extract one of the channels broadcast by the Blueline Digital MKII transmitters.The device can be powered by both PoE and external power supply.
Main information
- 1 stereo channel.
- Euroblock connectors.
- Possibility of PoE power supply.
- Configurable through Worcad 3 software.
| No. Channels | 1 canal estéreo (desbalanceado) o 1 canal single/mono (balanceado)/ 1 stereo channel (unbalanced) or 1 single / mono channel (balanced) |
| Connections | Audio Out: Euroblock, 3 pin 5.08mm; Network: RJ-45; |
| Output sensitivity | -1.15 dBu (640mVrms) |
| Audio over IP | BlueLine UDP datagrams |
| Ethernet | 100 base TX |
| Consumption | 1,5 W |
| Power supply | PoE Class: Class 0 802.3af; External source: 12/24 Vdc (Not included) |
| Control protocols | OSC |
| Audio extraction modes | Stereo / Single / Mono |
| Weight(kg) | |
|---|---|
| Product | 0.36 |
| Box | 0.45 |
